G322-8 Automatic all servo driven screen printer

Short Description:

Product Detail

Product Tags


All shapes of glass bottles, cups, mugs at high production speeds. It can print any shape of containers all around in 1 print.

General Description

1.Silane or Pyrosil pre-treatment system optional
2.Automatic printing system with all servo driven: printing head, mesh frame, rotation, printing station up/down all driven by servo motors.
3.All jigs with individual servo motor driven for rotation
4.Auto UV curing after each printing. LED or Microwave UV system from USA, Electrode UV system from Europe
5.Quick and easy change over from one product to another. All parameters setting simply in touch screen.
6.PLC control & touch screen operation system, touch screen with Wifi for internet connection, easy for future maintenance and program upgrading Safety operation with CE


1.Second color can be replaced with hot stamping head if the first color is UV print
2.Simplified model: G323-328R for cylindrical bottles only.


Parameter \ Item 322-8
Power 380VAC 3Phases 50/60Hz
Air consumption 5-7 bars
Max printing speed (pcs/min) 30-50
Printing  Diameter 25--90mm
Product height 50-300mm
UV power 5kw electrode, 200-240w/cm


jty (1)
jty (2)

Main parts of the machine

Servo motor: Mitsubishi
PLC: Mitsubishi or Beckhoff
Indexer: Sandex (Japan)
Main motor: Tsubaki (Japan) or SEW (Germany)
UV system: HPE
Invertor: Panasonic
Relays: Omron
Sensors: Omron
Switches and other electronics: Schneider, Hager, etc.

Why choose us?

Compare with other suppliers in China.
1. Indexer: we use bigger indexer, and more powerful driven motor, so the speed of our machine is about 30% faster than theirs.
2. Rack: our machine's framework is more stable and stronger than theirs, which allows our machine stable running at higher speed.
3. Servo system: We use all Mitsubishi high quality servo motors, while the competitor is using servo motor made in China.
4. Servo module: we use high quality servo module from Taiwan made by professional supplier, while the competitor is making the module by themselves. The high quality servo module ensure the durability and better accuracy
5. Servo rotation: we use a gearbox to connect servo with fixture, so the fixture(products) rotation more stable and powerful, they connect servo with fixture directly. And in many cases the servo alarm due to less power for rotation
6. Loading and unloading: they use very simple and weak robot, very slow, we use servo robot arm, faster, stronger and more stable.
7. UV: their UV lamp use a Chinese brand, bad quality and no enough power. We use UV system from Europe. And the UV shuttle of the competitor is a poor design which  slow down the speed a lot
8. Pre-treatment: we are the only manufacturer in all over the world who is professional in 2 kinds of pre-treatment for glass. We have European Pyrosil treatment, and American Silane treatment. So far, there is no Chinese manufacturer who can offer any pre-treatment for glass. And pre-treatment is the key for adhesion
9. Market: we sell our machines mostly in Europe and USA with a very good reputation in the market. 80% of our machines are for oversea market. Our competitor is mostly sell the machines in domestic market. Bad news is, 80% of their machines in Chinese market are sleeping, mainly due to the adhesion problem, and servo alarm due to lack of stability
10. Experiences: we are not only making machines for glass, we are also printing wine bottles for a huge company Wonderful in USA. We have a full line of automatic glass printing system for their bottles every year. By years of printing, we are a lot more professional in glass printing. We know not only machine manufacturing, but also all about printing, such as ink, mesh, adhesion, pre-treatment... We transfer all the experiences to our customer free of charges.
